Withstanding Voltage |
AC 3700V 1 minute max. (Between the core of CT and outer case) |
Storage Temperature |
-10℃ to ~ 60℃ < 70%RH ( without condensation ) |
Accuracy |
(23℃±5℃ 80%RH or less) |
Operating Temperature |
0℃ to ~ 40℃ < 80%RH ( without condensation ) |
Power supply |
SR-44(1.55V)×2 or LR-44×2 |
Power consumption |
5mW |
Weight |
Approx. 100g |
Measuring Range |
AC Current:30A/300A (2 ranges auto) AC Voltage:3V~500V (4 ranges auto, 50/60Hz) DC Voltage:300mV~500V(5 ranges auto) Resistance:300Ω/3000Ω (2 ranges auto) |
AC Conversion |
Average sensing rms reading |
Safety standard |
IEC61010-1, IEC61010-2-032 Installation CategoryⅡ 600V or CategoryⅢ 300V |
Jaw opening capability |
40mmφ |
Limitation of circuit voltage |
Less than AC 500V |
Size |
64(W)×193(H)×24(D)mm |
